Products / Threaded Inserts For PCB / Broaching Stud For PCB



Deepak Brass Industries Broaching studs provide strong male threads in non-ductile materials such as printed circuit board, polycarbonate, acrylic, glass epoxy and resin laminate components as well as ductile panels.

Material : Carbon steel (finished in electro tin plating (zinc optional)), 300 series stainless steel (finished per Passivated ASTM A380), Brass, Phosphorous Bronze

Available thread sizes :

Inches :
  • #2-56
  • #4-40
  • #6-32
  • #8-32
  • #10-24
  • #10-32

Metric :
  • M2 x 0.4
  • M2.5 x 0.45
  • M3 x 0.5
  • M4 x 0.7
  • M5 x 0.8

The broaching type Stud from Deepak Brass Industries can be used as a Solderable connector, or as threaded fasteners and is a regular selection for use in printed circuit board materials. They can be quickly and easily Installed and provide an attachment that is permanent and Strong.

Applications


Threaded Inserts for Plastics, Threaded Inserts for Thermosetting Plastics, Threaded Inserts for Thermoplastics, Threaded Inserts for Injection Moulding, Threaded Inserts for Sheet Metals. Threaded Inserts for Woods, Timber, Plywood & Laminates, Threaded Inserts for Fibreglass, Threaded Inserts for Epoxy & Rubber, Threaded Inserts for PCBs, Custom Inserts for various Fastening Solutions.

Material :
Our Threaded Inserts are available in Brass, Stainless Steel, Carbon Steel, Aluminium & Silicon Bronze material as per Fastening Applications.
